Convert logs to metrics in legacy applications using Fluent Bit

Green circular chart with a white upward trending line overlaying digital paper icons and binary code on a dark background.
ACF Image Blog

Legacy applications may not emit the telemetry data you need. Learn how you can convert logs into metrics with Fluent Bit.

Fluent Bit logo
Sharad Regoti Guest author

Sharad Regoti is a CKA & CKS certified software engineer based in Mumbai.

12 MINS READ

When you have logs but need metrics

In software development, observability allows us to understand a system from the outside by asking questions about the system without knowing its inner workings. Furthermore, it allows us to troubleshoot easily and helps answer the question, “Why is this happening?”

To be able to ask those questions to a system, the application must be instrumented. That is, the application code must emit signals such as traces, metrics, and logs that can be consumed into an observability solution like Chronosphere Platform.

Most modern applications are instrumented to output telemetry signals. However, at times you may find yourself working with systems that may not provide all the telemetry data you need. This is often the case when working with legacy applications, which may offer only a subset of the essential telemetry signals and whose codebase cannot be instrumented to provide more.

In such challenging situations, innovative solutions become imperative. You may have to derive telemetry data from other means.

This is where Fluent Bit comes into play. Fluent Bit is a widely used open source data collection agent, processor, and forwarder that enables you to collect logs, metrics, and traces from various sources, filter and transform them, and then forward them to multiple destinations. It also ingeniously addresses the aforementioned issues.

In this blog, we will demonstrate how Fluent Bit can derive metrics from application logs, helping to bridge the gap between limited telemetry sources and comprehensive system observability.

Use case: getting metrics from legacy applications

Consider a legacy application that logs HTTP requests and their corresponding status codes during processing. Here is an example log:

{
  "host": "31.163.219.152",
  "user-identifier": "-",
  "datetime": "31/Oct/2023:04:30:04 +0000",
  "method": "GET",
  "request": "/optimize/exploit/architect",
  "protocol": "HTTP/2.0",
  "status": 201,
  "bytes": 21985,
  "referer": "<http://www.leadschemas.biz/syndicate/seamless/experiences/repurpose>"
}

The challenge is to identify the HTTP Request Rate and Error Rate. However, instrumenting the application to generate metrics is not feasible, as it was developed using an outdated programming language version, and the existing instrumentation libraries do not support this older version.

However, because the application log already contains status and request information. We can extract this data and convert it into metrics.

Prerequisites

  • Kubernetes Cluster: We will deploy Fluent Bit in a Kubernetes cluster. We will be using an EKS cluster, but any cluster will suffice.
  • Kubectl and Helm CLI: Installed on your local machine.
  • Familiarity with Fluent Bit concepts: Such as, inputs, outputs, parsers, and filters. If you’re not familiar with these concepts, please refer to the official documentation.

Deploying a sample legacy application

Let’s deploy our legacy application into Kubernetes. For demonstration purposes, we’ll use a fake log generator.

Instructions:

1) Save the below deployment configuration in a file called application.yaml.

apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app: legacy-application
  name: legacy-application
  namespace: default
spec:
  replicas: 1
  selector:
    matchLabels:
      app: legacy-application
  template:
    metadata:
      labels:
        app: legacy-application
    spec:
      containers:
        - image: mingrammer/flog:0.4.3
          name: legacy-application
          args: ["--loop", "--delay", "2", "--format", "json"]

2) Now, apply the configuration using the below command:

kubectl apply -f application.yaml

3) View the application logs

kubectl logs deploy/legacy-application

A screen filled with coded text and log entries, processed by Fluent Bit, displays various HTTP request methods, URLs, protocols, status codes, and timestamps in a terminal interface.

Converting logs to metrics

Metrics are usually stored in a time series database such as Prometheus, InfluxDB, etc. These databases require metrics to be stored in particular data types such as counter, gauge, and histogram.

Converting raw logs into structured metrics involves a systematic approach.

Rules for converting logs to metrics

  1. List the required metrics:
    As discussed above, we want two metrics: HTTP request rate and HTTP error rate.
  2. Identify corresponding log values:
    From application logs, the request field contains the endpoint path for HTTP requests, which can be mapped to the HTTP request rate metric while the status field indicates the HTTP status code. It ranges from 200 to 599. We are particularly interested in monitoring status codes greater than 500, indicating server errors that can be mapped to the HTTP error rate.
  3. Determine the metric type:
    • HTTP request rate (e.g., requests per second):
      • Appropriate metric type: Counter
      • Explanation: Counters are ideal for measuring rates, such as the total number of HTTP requests served. To calculate the request rate, take the derivative of the counter value over time. This yields metrics like requests per second (RPS) or requests per minute (RPM) based on our preference.
    • Error rate (based on HTTP status codes):
      • Appropriate metric type: Counter or Gauge
      • Explanation: Counters are commonly used to calculate error rates derived from HTTP status codes. You can create counters like http_errors_total{status="4xx"} to tally 4xx client errors or http_errors_total{status="5xx"} for 5xx server errors. Counters are suitable because they steadily increase, providing a cumulative count of errors over time.

With the prerequisites for metrics now elucidated, let’s implement it in practice.

Configure Fluent Bit

Flowchart showing how Fluent Bit converts logs to metrics and pushes them to Prometheus. Steps include input, filtering (using Rewrite Tag plugin), output (exposing metrics using Prometheus plugin), and pull by Prometheus. Ideal for modernizing legacy applications with efficient log management.

Here’s the Fluent Bit configuration that enables the log processing pipeline depicted above:

config:
  customParsers: |
    [PARSER]
        Name         crijsonparser
        Format       regex
        Regex        ^(?

Breaking down the configuration above, we define one input section:

    • This input section exclusively targets Legacy Application container logs running in the default namespace, marked with the tag kube.*.

The filter section comprises four filters:

1) Rewrite Tag Filter: This section selects all the logs that match the tag kube.* and applies the regex \"request\"\s*:\s*"\s*\/[^"]+". For logs that satisfy the regex expression we apply the tag http_requests_total. The configuration value of the Rule field is mapped to the format $KEY REGEX NEW_TAG KEEP.

  • $KEY: The key represents the name of the record key that holds the value that we want to use to match our regular expression. In our case, it is log as the record generated by tail plugin stores the log message under the key named log.
    • "request" matches the literal string “request”.
    • \s*:\s* matches the colon (:) with optional spaces before and after.
    • "\s*/[^"]+" matches a double quote (“) followed by a slash (/) and then one or more characters that are not double quotes, ending with a double quote.
  • Regex: Using a simple regular expression, we specify a matching pattern to apply to the value of the key specified above. Here is the breakdown of the regex that we used:
  • New Tag: If our regular expression matches the value of the defined key in the rule, we apply a new Tag for that specific record: http_requests_total.
  • Keep: If a rule matches, the filter emits a copy of the record with the newly defined Tag. The keep property takes a boolean value to determine whether the original record with the old Tag should be preserved and continue in the pipeline or be discarded. In our case, we will be setting it to true because we might want to send the original records (logs) to some other destination.

For more information about this plugin, check the official documentation.

2) Log to Metrics Filter: This plugin allows you to generate log-derived metrics. It currently supports modes to count records, provide a gauge for field values, or create a histogram. As noted above, we have configured this filter to catch records with the tag http_requests_total and convert it into a counter metric. After conversion, the generated metric gets a new tag called metrics.

Note: the Fluent Bit Logs to Metric filter includes a Regex configuration parameter used to match which logs should be converted to metrics. However, it fails to match when the value is numeric (http status code) rather than text. Hence the need for the Rewrite Tag Filter. Another option would be to use the Fluent Bit Lua filter to write a custom script that would convert the numerical value to a text string. You can track the issue status on GitHub.

These same two filters also operate on logs that satisfy the regex \"status\"\s*:\s*5\d{2}, which captures logs having a status code greater than 500 for calculating HTTP Error Rate. Here is the breakdown of the regex:

  • "status": Matches the literal string “status”.
  • \s*: Matches zero or more whitespace characters.
  • :: Matches the colon character.
  • \s*: Matches zero or more whitespace characters.
  • 5\d{2}: Matches a number starting with 5 followed by exactly 2 digits (\d represents any digit).

For more information about this plugin, check the official documentation.

Further down the pipeline, the output section consists of one output:

    • Prometheus: This section matches all the records that have tag metrics and exposes them for Prometheus to consume on port 2021 of the Fluent Bit container. For more information about this plugin, check the official documentation.

Deploy our Fluent Bit configuration

Let’s deploy the above Fluent Bit configuration using the Helm chart available at Fluent Bit Helm Chart.

1) Add Fluent Bit Helm repo

Use the command below to add the Fluent Bit Helm repository:

config:
  customParsers: |
    [PARSER]
        Name         crijsonparser
        Format       regex
        Regex        ^(?

3) Deploy Fluent Bit

Use the command below:

helm upgrade -i fluent-bit fluent/fluent-bit --values values.yaml

4) Wait for Fluent Bit pods to run

Ensure that the Fluent Bit pods reach the Running state.

kubectl get pods

Deploy Prometheus and visualize our metrics

Create a file called prometheus.yaml with the following contents:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: prometheus
spec:
  replicas: 1
  selector:
    matchLabels:
      app: prometheus
  template:
    metadata:
      labels:
        app: prometheus
    spec:
      containers:
      - name: prometheus
        image: prom/prometheus:v2.47.2
        ports:
        - containerPort: 9090
        args:
        - "--config.file=/etc/prometheus/prometheus.yml"
        volumeMounts:
        - name: config-volume
          mountPath: /etc/prometheus
      volumes:
      - name: config-volume
        configMap:
          name: prometheus-config
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: prometheus-config
data:
  prometheus.yml: |
    global:
      scrape_interval: 5s

    scrape_configs:
      - job_name: 'legacy-application'
        static_configs:
          - targets: ['fluent-bit.default.svc.cluster.local:2021']
---
apiVersion: v1
kind: Service
metadata:
  name: prometheus-service
spec:
  selector:
    app: prometheus
  ports:
    - protocol: TCP
      port: 9090
      targetPort: 9090
  type: ClusterIP

Apply it using kubectl apply -f prometheus.yaml

Open the Prometheus console locally using the command below:

kubectl port-forward service/prometheus-service 9090:9090

To see the http request rate metric, execute the following PromQL query:

rate(log_metric_counter_http_requests_total[1m])

A line graph from Prometheus showing HTTP requests total over time. The green line spikes sharply at the middle of the graph and remains constant until the end, effectively turning logs to metrics for better monitoring of legacy applications.

To obtain the http error rate, execute the below PromQL query:

rate(log_metric_counter_http_status_500_total [1m]) / rate(log_metric_counter_http_requests_total [1m])

Line graph generated on the Prometheus interface showing HTTP 500 status metrics over time, with a notable increase around 4:30 am. Several options like "Enable query history" are toggled on. Fluent Bit was utilized to convert logs to metrics, providing deeper insights into legacy applications.

Conclusion and learn more about Fluent Bit

The Fluent Bit Logs to Metrics filter solves the challenge of bringing observability to legacy applications by transforming commonly available log data into metrics that can be stored in a time series database for visualization and analysis.

Converting logs to metrics is just one way that Fluent Bit enables users to process in-flight data as it flows through the pipeline before arriving at its destination. Fluent Bit can also redact or enrich your data and analyze it to determine where it should be routed based on your business rules.

To learn more about Fluent Bit and its capabilities, download a free advance copy of Fluent Bit with Kubernetes by Phil Wilkins published by Manning Publications.

A promotional image displaying an offer for a free copy of the book “Fluent Bit with Kubernetes.” The book cover shows an illustration of a person and MEAP stamped on it. Logos of Chronosphere and Calyptia are also visible.

About Fluent Bit and Chronosphere

With Chronosphere’s acquisition of Calyptia in 2024, Chronosphere became the primary corporate sponsor of Fluent Bit. Eduardo Silva — the original creator of Fluent Bit and co-founder of Calyptia — leads a team of Chronosphere engineers dedicated full-time to the project, ensuring its continuous development and improvement.

Fluent Bit is a graduated project of the Cloud Native Computing Foundation (CNCF) under the umbrella of Fluentd, alongside other foundational technologies such as Kubernetes and Prometheus. Chronosphere is also a silver-level sponsor of the CNCF.
